Automatic High Speed Alu-PVC/Alu-Alu Blister Capsule Packing Machine
Purpose
DPP-260H2 automatic ALU-PVC and ALU-ALU blister packing machine is our latest improved equipment, adopts inverter control and integrated mechanical, electrical, optical, pneumatic control technology. Its innovative design meets pharmaceutical industry (GMP) standard strictly, is leading in China, this machine has features such as advanced function, simple operation, high output, is the most ideal packaging equipment in large and medium size pharmaceutical enterprises, healthcare products and food industry.
Performance features
(1) adopt Siemens PLC programmable control, wonderful touch screen operation, frequency control, servo with speed reducer traction, traction length may be adjusted at will on the touch screen within the scope of technical parameters, could avoid errors caused by manual mechanical adjustment, reduce labor intensity and waste of consumables greatly;
(2) have functions such as heating temperature control detection, control, uniform die heating, host overload protection, PVC and PTP packing material level detection and alarm shutdown, automatic diagnosis alarm prompt for equipment fault and automatic shutdown protection;
(3) feeder adopts steam vibration feeding and bunker level detection control, reduce long time mixing friction of materials greatly, so as to protect material integration;
(4) level detection device is installed for feed hopper, if level is insufficient, host will prompt and enter shutdown status, ensure feeding integrality of each plate, increase product qualification rate;
(5) stations of the complete machine adopts fast loading structure design, suitable for multi-variety production, dies may be replaced more conveniently and reliably (only about 30 min is required from replacing die to production);
(6) contact heating, positive pressure formation, air cushion heat seal for female/male checkered plates;
(7) adopt special processing and assembly process to ensure balanced running of aluminum foil without offset or jitter, promote more accurate, stable alignment of graphic text;
(8) have two enlarged PVC bearing platforms for fast replacement, overall guide rail for the complete machine, could enhance practicability of the complete machine;
(9) rectangular design, "T" positioning of the die facilitate die replacement, all parts that contact with medicaments are made of high quality stainless steel and high quality aluminum alloy, top grade surface treatment process highlights tactile sensation;
(10) have automatic scrap rolling mechanism, scrap may be collected easily, finished products are output orderly, conveyor belt is provided at the outlet to provide necessary conditions for follow-up equipment and production;
(11) one machine dual purpose, aluminum-plastic or aluminum-aluminum varieties may be produced only by replacing a small part of structure;
(12) the complete machine adopts split connection design, could enter elevators, workshops easily.
Technical specifications
Model | DPP-260H2 |
Cutting Frequency | AL/PL:25-60times/min AL/AL:20-30times/min |
Production Capacity | ALU-PVC:140,000tablets or capsules/hour, ALU/ALU:75,000tablets or capsules/hour |
Max forming depth | ALU/PVC:22 mm ALU/ALU:18mm |
Travel scope | 30-120 mm (made to order 140mm) |
Total power | 380V 50Hz8. 5KW |
PVC hard pieces | 0. 25-0. 5×260 mm |
Dialyzing paper | 50-100g×260 mm |
PTP aluminum foil | 0. 02-0. 035×260 mm |
Cooling system | Cold water circulating (optional) |
Air consumption | ≥0.2m 3 /min |
Total dimension | 4580×780×1620mm |
Weight | 1850kg |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
