fully automatic stretch wrap packing machine
1. wide application
suitable for vacuum or air charging fully automatic draw hot seal packing in food, fruit, vegetable, marine products, frozen meat, bean product, Chinese traditional medicine, hardware, electronic element and medical apparatus etc.
2. advanced controlling system
The series packing machine adopts Japan mitsubishi touching screen, PLC and step-motion control system. simple adjustion, high step control precision, harmonious action, high automation
3. complete function
(1)covering film can choose color film or light film. Through simple operation, choose color film or light film on same equipment.
(2)Equip automatic coding system according to the requirements of consumers.
(3)Based on vacuumization according to the requirement of consumers, charge N2,02,CO2 mixed gas or single gas. Mixed proportion can be adjusted by air controller.
(4)Equipped with origiral German vacuum pump.
main parameter:
Model | DLZ320 | DLZ420 | DLZ-520 |
Voltage | 380V.50HZ | 380V.50HZ | 380V.50HZ |
Power | 8KW | 10KW | 12KW |
Size mm | 3800×900×1600 | 4200×900×1600 | 7000×910×1700 |
Width of upper | 293mm | 393mm | 496mm |
Width of lower | 322mm | 422mm | 522mm |
Vacuum | ≤0.5mbar | ≤0.5mbar | ≤0.5mbar |
Compress air | ≥0.5Mpa | ≥0.5Mpa | ≥0.5Mpa |
Cooling water | ≥0.15Mpa | ≥0.15Mpa | ≥0.15Mpa |
Machine weight | 900kg | 1300kg | 1800kg |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
SUPM is a national high-tech enterprise integrating R&D, production, sales and related services of pharmaceuticals, food, cosmetics industries.
