Hotpharma Packing Machine Automatic Cartoning Machine SUPM Brand
Product details of the pharma packing machine
Product Specification
Trademark: SUPM
Name: automatic cartoning machine
Product Description
SUPM pharma packing machine is manufactured using quality raw material in accordance with industry defined standards. With the pharma packing machine,it's unnecessary for you to worry about quality problem. pharma packing machine is made up of superior raw material to achieve quality assurance.
Automatic Bottle Packing Cartoning Machine
Automatic bottle packing machine is suitable for insert blister, bottle, vial, tube, sachet, injection, condom.InstructionThis equipment is new model developping base on integrated domestic and foreign advance technology. It is high technology product incorporates pneumatic-photo-electro-mechanic which improve by a large on performance of equipment and working efficiency, realize encasing fast, keep running steady and reliable when fast running. This machine is suitable for automatic feeding bottle(round, square bottle) into carton. On line bottle unscramble and feeding, leaflet fold(1-4folds) and feeding, leaflet detecting, carton opening and forming, products and leaflet pushing into carton, printing batch mumber, sealing carton with tuck-in or hot melt glue device. Automatically reject lacking of leaflet or prodcut and finished product out.Feature1. International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.2. Adopt human-machine operation system.3. Automatically displaying device for trouble, speed and finished products counting.4. Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.5. No products not suction leaflet, no leaflet not suction carton.6. Automatic detection and rejection device for lacking blister goods and leaflets.7. Protecting automatically for overloading8. Stable performance, operation is easy.
| Main technical parameters | ||
| Encasing speed | 30-100 boxes/min | |
| Box | Quality requirement | 250-350g/m 2 |
| Dimension rangeL×W×H | (65-180)mm×(35-85)mm×(14-50)mm | |
| Quality requirement | 60-70g/m 2 | |
| Leaflet | Unfolded leaflet specificationL×W | (80-250)mm×(90-170)mm |
| Fold range | (1-4) fold | |
| Compressed air | Working pressure | ≥0.6mpa |
| Air consumption | 120-160L/min | |
| Power | 220V/50Hz | |
| Motor power | 0.75kw | |
| Machine dimension(L×W×H) | 3100mm×1100mm×1550mm | |
| Machine weight | 1400kg | |
More pictures
![RX2]L7{%NOW0`YXF9~)M{_G](http://img.yfisher.com/m5591/171695526519cd71.png)
Company Advantage
• SUPM provides a full range of services, such as comprehensive product consultation and professional skills training.
• SUPM's machinery is made based on advanced production technology. They are self-adaptation, maintenance-free, and self-testing. They are of simple operation and great practicability.
• SUPM's location has traffic convenience with multiple traffic lines joining up. This contributes to the transportation and ensures the timely supply of products.
• We have been adhering to the concept of 'customer first, attentive service'. According to the actual needs of customers, we could develop and produce high-quality products, to help customers solve problems. Besides, we provide customers with efficient and professional custom services.
• SUPM has a highly educated and professional technical team. Our team members provide related technical support according to production demand, so as to promote the production of quality products.
For more styles, please contact SUPM to get detailed information.
SUPM is a national high-tech enterprise integrating R&D, production, sales and related services of pharmaceuticals, food, cosmetics industries.
