Multi Lane Stick Pack Machine by SUPM
Product details of the multi lane stick pack machine
Product Information
When it comes to comparing with other products, our multi lane stick pack machine is of greater appearance. We conduct a variety of rigorous tests to ensure that our products are defect free and meet high quality standards. Professional and thoughtful customer services are provided by Shanghai Universal Pharmaceutical Machinery Co.,Ltd..
I. Main performance and structure features1. Double transducer control, flexible bag length cutting, operator needn't to adjust the unloading working, saving time and saving films.2. Human-machine operation, convenient and quick parameter setting.3. Self diagnosis failure function, clear failure display.4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.5. Separate PID control to temperature, suitable for various packing materials.6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.7. Simple driving system, reliable working, convenient maintenance.8. All the controls are achieved by software, convenient for function adjusting and upgrading.II. ApplicationIt is especially suitable for packing blistersinto pillow bags in pharmaceutical industry.Also it is suitable for packing regular objects such as biscuit, bread, instant noodle, moon cakes, industrial parts, paper box or trays.III. Optional device1. Code applying machine2. Line sealing wheel3. Moire terminal sealing mould4. Extra big screen
| Type | KDT-450 |
| Film width | Max.450mm |
| Bag length | 150-450mm |
| Bag width | 30-190mm |
| Product height | Max.80mm |
| Film roll diameter | Max. 320mm |
| Packaging rate | 40-180bags/min |
| Power | 220V,50/60HZ,2.8KVA |
| Machine size | (L)4020X(W)800X(H)450mm |
| Machine quality | about 580kg |
| Remarks |
1.Nomally shipping steps:
2.Our packing and shipping:
Pre-Sales Service:
* Inquiry and consulting support.
*Quickly reaction.
*Factory inspection available anytime.
After-Sales Service:
*Prompt technical support
*Engineers available to service machinery overseas
*Installation &commissioning,good training for customers.
Q1.What's your delivery method?
A1:We commonly use sea transportation, using container to deliver the goods through Shanghai Port.
Q2.What products can you provide?
A2:Our main product includes powder mixers,granulating equipments,drying equipments,capsule fillers,blister packing machines,tablet/capsule counting filling line,ampoule/vial/oral liquid filling line includes ultrasonic washing machine,sterilization oven,filling capping machine,labeling machine.
Q3. What's the payment terms?
A3:We will confirm the payment with you when quoting, like FCA, CIF or others.T/T is the main payment.
Q4.How do you ensure your product quality?
A4:We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
Q5:Does the machine power voltage meet buyers' factory power source?
A5: We can do it as your request.
Q6: Is it difficult to install the machine ?
A6: For standard small machines, the machines will be packed with no take apart, it comes to you to be a complete machine; you just need to connect power and compressed air to machine, then begin to operate the machine.
For large size machines, we will take the machine apart, on condition that we do our best to keep the machine easy to assembly.
You will get videos and instructions about installation of machine from us.
Company Advantage
• SUPM has a complete after-sales service system to solve problems for customers.
• SUPM's products have been loved and recognized by people of many countries and have been sold well both at home and abroad.
• The mechanical equipment produced by SUPM has complete and diversified types. And it is highly practical, with reliable quality and reasonable price.
• Our company has a high-standard, high-demand, high-efficiency, high-capacity team composed of experienced professionals, which provides a powerful force for to manufacture better products.
• Our company owns a superior geographical location. There are convenient transportation, elegant ecological environment and abundant natural resources.
Large margin sales are going on. The more you buy, the more cost-effective price you will get. For details, please consult SUPM.
SUPM is a national high-tech enterprise integrating R&D, production, sales and related services of pharmaceuticals, food, cosmetics industries.
