Product details of the pharma packaging line
Product Specification
Origin: China
Trademark: SUPM
Name: Cartoning Machine
Product Description
In the design of SUPM pharma packaging line, we pay close attention to its aesthetics. The quality of this product can be guaranteed with the support of the QC team. This product is favored and trusted by customers.
Jdz-120d Automatic Cartoning Machine
General Description:This equipment is new model developping base on integrated domestic and foreign vanguard technology .It is high technology product incorporates pneumatic-photo-electro-mechanic which improve by a large on performance of equipment and working efficiency, realize encasing fast, keep running steady and reliable when fast running.This machine is suitable for condom, pouch, soft al/al strips, wound plaster, ointment plaster, facial mask plaster, coffee bag into carton. On line product feeding and detecting, leaflet fold (1-4folds) and feeding, leaflet detecting, canton opening and forming, products and leaflet pushing into carton, printing batch number, sealing carton with tuck-in or hot melt glue device. Automatically reject lacking of leaflet or product and finished product out.Weight & Dimensions:
| Type | JDZ-120D |
| Dimensions in mm | 2880mm×1140mm×1800mm (L×W×H) |
| Weight in kg | 1500 |
Output & Speed:
| Steady speed | 30-60 cartons/min |
Unfold Leaflet (optional):
| Grammage | Between (60-70)g/m2 |
| Size range | (80-250) ×(90-170)mm (L×W) |
| Fold range | (1-4 )fold |
| Notice: The leaflet can be folded by the machine | |
Carton and sachet:
| Grammage | Between( 250-350)g/m2 |
| Carton Size mm | (65-125)×(30-85)×(12-50)mm |
| Sachets/box | 1-12 |
| Sachet size mm |
| Standard power supply | 220V - 50Hz |
| Power consumption in KW | 1.1 |
| Air consumption | 120-160L/min |
| Compressed Air Pressure | 0.6MPa |
| Noise | <70 dB |
More pictures
Company Feature
• SUPM's Tablet pressing,capsule filling machine,blister packing machine,cartoning machine,filling and ca are reasonably designed. They are stable in performance and easy in operation. They are quality-reliable and use-durable.
• SUPM was founded in Over the years, we strive to learn foreign and domestic advanced manufacturing experience and continuously improve production technology. We improve the corporate governance system and pursue excellence in development. We establish a good corporate image in the industry.
• SUPM puts customers first and make effort to provide quality and thoughtful services based on customer demand.
• Our company formed an excellent R&D and design team. According to customers' needs, we could quickly design the best solution and provide quality custom services for customers.
• has a team formed by professional and technical personnel and high-quality management talents.
SUPM's Tablet pressing,capsule filling machine,blister packing machine,cartoning machine,filling and ca are trustworthy with excellent quality and favorable price. Please contact us as soon as possible if you need it!
SUPM is a national high-tech enterprise integrating R&D, production, sales and related services of pharmaceuticals, food, cosmetics industries.
