Main features of the machine:
1. This device is a fully automatic hard capsule filling device with intermittent action and hole plate filling. The filling and rotating parts are fully closed, and the upper mold seat is designed to be beautiful and generous without dead corners, making cleaning convenient and fast.
2. The upper and lower modules operate in one direction, with imported double lip polyurethane sealing rings for good sealing performance.
3. The module cleaning station combines blowing and suction to ensure that the high-speed operation of the mold hole is dust-free.
4. The locking station is equipped with a powder suction device.
5. The finished product dispensing station is equipped with a cartridge ring, which prevents dust from flying.
6. The material of the measuring disc is made of copper, which increases wear resistance and is not easily deformed
Technical Parameters
Model |
NJP-3500C |
Max.output capacity |
210,000 capsules/hour |
No.of segment bores |
25 |
Suitable for capsule size |
00-5 |
Total power |
11.5Kw (standard) |
Overall weight |
2200Kgs |
Overall dimensions |
1435(+550)mm×1248(+282.5)mm×1960mm |
Dust |
20Kpa 210m3/h |
Noise |
<75DB (A) |
Vacuum |
Pumping rate 72m3/h, -0.03-0.05MPa |
Filling error |
±2.5%—±3.5% |
The NJP-C series fully automatic capsule filling machine adopts PLC programming, stepless frequency conversion speed regulation, human-machine interface operation, and touch screen display. Automatic alarm display for operational faults or material shortages, automatic shutdown, and automatic elimination of alarms after troubleshooting. The machine also has functions such as password input, parameter setting, printing data, and resetting. All key components such as transmission shafts, camshafts, and bearings of the machine are made of imported materials, and the equipment quality is reliable. It is a stable equipment for filling capsule drugs and fully complies with GMP requirements.
The NJP series fully automatic capsule filling machine adopts Siemens from Germany's human-machine interface, PLC programmable controller, LCD display of production per minute, cumulative production, dynamic empty capsule and powder status, capsule shortage alarm prompt, automatic shutdown when powder is insufficient, fault diagnosis prompt, etc.
Small size, low energy consumption, fast mold replacement, convenient operation, and easy cleaning; Adopting Ferguson transmission, with low vibration, working noise below 75dB during high-speed operation, dose difference controlled within 3-5%, and capsule loading rate greater than 99.99%;
The rotating part is fully enclosed, with good lubrication conditions, and the workbench is free of oil stains, avoiding cross contamination with drugs;
There are barriers around the dose tray, which effectively recycle and reuse the powder thrown out of the lower surface of the dose tray through another pipeline, while reducing the dust on the workbench
automatic capsule flling machine adopts intermittent rotary operation, orifice plate type dosing flling, precise and compact design, stable and reliable running.It can automatically complete sowing, separating, flling, rejecting, lock capsule and finished product exported and a variety of processes. Fully enclosed twelve stations turntable, the module is designed in a double rows of 25 holes.It is an intelligent device for the production of hard capsules in the pharmaceutical and food industries.
