Product details of the pharmaceutical blister packaging machine
Product Specification
Origin: China
Trademark: SUPM
Name: Two dimensional motion mixer
Product Introduction
Designed by professional designers, SUPM pharmaceutical blister packaging machine is more unique than other products in the industry. This product has long service life and excellent performance. This product has obtained unanimous favorable comments in domestic market.
Applications& Feature:This mixer is widely used in pharmaceutical, chemical, food, dye, chemical fertilizer and pesticide industries and especially suitable for mixing various solid materials with large volume (1000tp-10000litres).The mixing barrel swings while rotating so that the materials in the barrel can be fully mixed. Because the discharge outlet of the barrel is out of the barrel centre line, the mixer features quick mixing and discharging, as well as high volume mixing capacity.
| Model of mixer | Barrel volume (L) | Loading volume (L) | Max.loading capacity(kg/batch) | rotation(rpm) | Total motor power(kw) | Dimension(mm) | Total weight (kg) | Drum Weight(kg) |
| EYH-10 | 10 | 5 | 2.5 | 85 | 0.021 | 310*400*450*395 | 15 | 4 |
| EYH-30 | 30 | 15 | 7.5 | 61 | 0.19 | 540*580*900*700 | 60 | 8.5 |
| EYH-60 | 60 | 30 | 15 | 50 | 0.4 | 700*730*1100*990 | 115 | 15 |
| EYH-150 | 150 | 75 | 37.5 | 37 | 1.15 | 800*1050*1450*1340 | 190 | 50 |
| EYH-300 | 300 | 150 | 75 | 30 | 1.15 | 900*1350*1550*1400 | 340 | 60 |
| EYH-600 | 600 | 300 | 150 | 23.6 | 3 | 1170*1640*2050*1910 | 1150 | 140 |
| EYH-800 | 800 | 400 | 200 | 19.8 | 3 | 1320*1950*2150*2000 | 1600 | 200 |
| EYH-1000 | 1000 | 500 | 250 | 19.8 | 3 | 1360*2, 040*2300*2170 | 1700 | 240 |
| EYH-1500 | 1500 | 750 | 375 | 16.2 | 4.4 | 1580*2400*2550*2330 | 2000 | 320 |
| EYH-2000 | 2000 | 1000 | 500 | 16.2 | 7.4 | 1740*2600*2770*2550 | 2600 | 430 |
| EYH-3000 | 3000 | 1500 | 750 | 13.8 | 11 | 1800*2900*2950*2800 | 3500 | 620 |
| EYH-4000 | 4000 | 2000 | 1000 | 12.8 | 13 | 1970*3300*3300*2950 | 4100 | 700 |
| EYH-6000 | 6000 | 3000 | 1500 | 11.2 | 18.5 | 2300*2900*3800*3100 | 6100 | 1100 |
| EYH-8000 | 8000 | 4000 | 2000 | 10.4 | 22 | 2540*4100*4050*3650 | 7900 | 1450 |
| EYH-10000 | 10000 | 5000 | 2500 | 9 | 30 | 2900*4500*4400*4020 | 9500 |
Company Advantage
• SUPM gathers a group of experienced technical and management talents in R&D, manufacturing, and after-sales service. We can provide high-quality custom services according to the needs of each customer.
• Compact in structure, stable in performance, reliable in quality, high in cost performance and wide in application, SUPM's mechanical equipment greatly improves production efficiency.
• SUPM's location has unique geographical advantages, complete supporting facilities, and traffic convenience.
• SUPM owns a comprehensive after-sales service system and information feedback channels. We have the ability to guarantee comprehensive service and effectively solve customers' problems.
• Our company has our own professional research and development team and our own unique advantages in technology development.
There is only part of pictures of our electric equipment displayed on our website. For more specific information, please consult SUPM. Thank you!
