1. Adopting single row 11 die holes and 10 workstations design, it becomes the filling equipment with high production efficiency of single row punching die group in China.
2、The original double RU110 indexing box is adopted to make reasonable adaption. The stability and service life of the machine are greatly improved.
3、Improve the transmission cam of all stations, use high-quality special steel to make inner groove wheel transmission, eliminate the drawbacks of spring pulling easy fatigue and fracture, and wear-resistant, stable operation.
4、 adopt the second generation totally enclosed turntable design. The upper die adopts two shafts to move up and down circumferentially, and imported silica gel seals to reduce the powder feeding into and out of the rotary table; the lower die adopts two shafts to move in and out circumferentially, matched with imported rubber seals to reduce the situation of powder feeding due to the back and forth expansion of the moving shaft, and it is stable and has high precision; the double shafts are made of a press cover, easy to disassemble and assemble, easy to clean, and the sealing ring is not changed. It is necessary to turn on the turntable to avoid cumbersome defects due to the dismantling of the turntable.
5、It adopts three dimensional control elements; and takes the undersurface plane of dosage as base, so as to eliminate the matural transmutation of the dosing disc and copper saucer, it is uniformity in interval and guarantees the accurate of filling weight, decreasing the phenomena of powder leak and dasy to clean, it’s the special design at design at domestic (Patent Number 20042006795X).
