metal detector
Characteristics:
1. The use of phase adjustment technology can effectively suppress product effects.
2. The use of high-speed digital signal processing devices and intelligent algorithms has improved detection accuracy and stability.
3. Can detect various metal materials such as iron, stainless steel, copper, aluminum, and lead.
4. LCD screen display, Chinese and English menu screen, easy to achieve human-machine dialogue operation.
5. The intelligent self-learning function can detect frozen foods (such as dumplings, frozen fish), meat, rice, pickled products, etc.
6. It has memory function, supports storing product parameters of multiple different products, and can adapt to more product groups.
7. Convenient detachable rack for easy cleaning by users.
8. The special design of the conveyor belt prevents it from deviating.
9. The performance price ratio is high, and the price is extremely attractive.
10. Made entirely of stainless steel, the whole machine has excellent waterproof performance. Load capacity ≤ 10Kg
Product Introduction
Principle:
Metal detectors use the principle of electromagnetic induction to generate rapidly changing magnetic fields through coils that pass alternating current. This magnetic field can induce eddy currents inside metal objects. Eddy currents can generate a magnetic field, which in turn affects the original magnetic field and causes the detector to emit a sound.
Product recognizable range:
Recognizable
A. Iron
B. Non ferrous metals with good conductivity, such as gold, silver, copper, etc
C. Magnetic stainless steel
Unrecognized
A. Non metallic materials such as plastic, stone, wood, etc
B. Content of metallic elements
C. Types of metals
Tasic parameters：
Channel size (mm) | 200*100 |
Effective passing height (mm) | 100 |
Effective passage width (mm) | 200 |
detection sensitivity | FE 0.8 SUS 1.5 |
Transportation method | Conveyor belt (belt width: 170mm) |
Operation screen display | Chinese or English |
Running direction | Facing the display screen, from left to right |
Belt speed | 30 meters |
Detection method | electromagnetic induction |
Alarm mode | The conveyor belt stops and beeps, triggering an alarm |
power | Approximately 220W |
Power Supply | Single phase AC220V |
weight | 150kg |
Material and surface treatment | Stainless steel 304 polishing treatment |
