Custom Automatic Tablet Inspection Machine UN-150 SUPM
UN-150 High Efficiency Check Weigher
Feature:
1.Reinforced stainless steel frame,all water-proof design,
2.It adopts Germany HBM high accuracy sensor,it is based on the most advanced digital signal processing technology,high speed is realized and stable checking,.
3.Dynamic weight automatic compensation technology,0 point automatic analysis and trace technology,
4.It has 50 groups of product preset,simple product edit and storage,
5.Quick product changing-over and automatic adjust the correspondent product sorting speed,
6.Convenient USB test data,copy,storage function(options),
7.Color LED touch screen operation system,multi language operation interface,simple operation,
8.It can optionally match scanning system and automatic inkjet printer.
Technical specifications:
| Weighing range | 3g-300g |
| Conveying speed(meter/minute) | 5-85m |
| Max. speed(bags/minute) | 70bags |
| Standard accuracy | ±5g |
| Width of conveyor belt | 150mm |
| Reject method | Rejected by pushing rod |
| Product preset mode | 50 group |
| Power supply | 220V50HZ,single phase |
| Power | 140w |
| Outer air supply | / |
| Air pressure connection size | 8mm |
| Reserve connection (option) | / |
Levels of protection |
Meets IP-30(PB)international standard (water-proof model meets IP-66 international standard) |
Weight |
95kg |
| The height from the floor to the conveyor belt | 730±50mm(can be customized according to actual condition) |
Standard part list:
| Name | Qty | Brand |
| Touch screen | 1 | Weinview |
| Motor | 3 | Taiwan taibang |
| Inverter | 1 | Japan MITSUBISHI |
| PLC | 1 | Japan MITSUBISHI |
| Belt | 3 | Switzerland Habasit |
| Pneumatic part | 1 group | Taiwan AirTAC |
| Sensor | 1 | Germany HBM |
| Photoelectric sensor | 1 | Japan OMRON |
| Air breaker | 1 | Japan MITSUBISHI |
| Relay | 2 | Japan OMRON |
Company Advantages
· The design of SUPM automatic tablet inspection machine is the combination of functionality and aesthetics.
· Advanced testing equipment and perfect quality assurance system ensure the product to be of great quality.
· SUPM has high commercial value due to its practicability.
Company Features
· Shanghai Universal Pharmaceutical Machinery Co.,Ltd. is an experienced manufacturer of automatic tablet inspection machine, with years of rich experience in design and production.
· Shanghai Universal Pharmaceutical Machinery Co.,Ltd. has established production and research bases with many famous universities.
· Our core value is always treating customers with respect and faith. Ranging from all aspects of our business processes, we always adhere to integrity and business ethics. Call!
Application of the Product
SUPM's automatic tablet inspection machine is widely used in various scenes.
We will communicate with our customers to understand their situations and provide them with effective solutions.
SUPM is a national high-tech enterprise integrating R&D, production, sales and related services of pharmaceuticals, food, cosmetics industries.
